Tergotometer

As per ASTM D-2300, BS 5797:1986, IEC 628:1985 Gassing Tendency Apparatus measures the tendency of insulating oil / liquids to evolve or absorb gas when subjected in cells having specific geometrics, electrical stress of sufficient intensity to cause an electric discharge through a gas phase in which a gas oil interface is located. Fully Made with Stainless Steel Assembly Gassing cell and gas burette assembly made of borosilicate glass with a relative permittivity of 5 ± 0.2 at 80°C. Hollow high-voltage electrode-made of centre less-ground and polished stainless steel with stainless steel capillary tubing as a gas passage. The electrode is supported by PTFE Plug Constant temperature oil bath with a heating and circulation with digital temperature control system. Transparent safety shield-made of clear view acrylic sheet. Power supply : 120 V / 230 Volt AC, 1 Phase, 50/60 Hz

Rotameters are devices which measure the flow rate of liquid or gas in a closed tube. This product is machined from clear acrylic block and is designed to give maximum accuracy in visibility and ruggedness. The floats are made from stainless steel, PVC and other non corrosive materials. The needle valve is provided for accurate flow control. It is designed to give accuracy of 0.5 to 1% at full scale. The higher accuracy can be made on specific requirement.

Rotameters are devices which measure the flow rate of liquid or gas in a closed tube. This product is machined from clear acrylic block and is designed to give maximum accuracy in visibility and ruggedness. The floats are made from stainless steel, PVC and other non corrosive materials. The needle valve is provided for accurate flow control. It is designed to give accuracy of 0.5 to 1% at full scale. The higher accuracy can be made on specific requirement.
