Name: EMCOR Rust Tester
Availability: instock

EMCOR Rust Tester

The EMCOR Rust Tester is designed to determine the corrosion-preventive properties of lubricating greases on ball bearings in the presence of water or salt water. The system replicates real-world mechanical and environmental conditions by rotating and resting the bearings in a water medium. It is built to conform with IP 220 , DIN 51802 and ASTM D6138, enabling both dynamic and static corrosion testing of greases. Key Features: 4 / 6 / 8 test setup for testing of bearings simultaneously Bearing housing in SS 316 for high corrosion resistance Powder-coated outer body for long life Operates at 80 RPM with automatic rest/run cycles Includes plummer blocks, adapter sleeves, self-aligning bearings, and V-ring seals Microcontroller-based Run/Rest Timer. Scope of Supply: EMCOR Test Rig with Base Plate Electric Motor with Gear System SS Shaft and Support Assembly Plummer Blocks & Bearing Housings Self-Aligning Bearings Adapter Sleeves & V-Ring Seals Electronic Run/Stop Timer User Manual Applications: Corrosion Testing of Grease in Bearings R&D Labs in Lubricant Industry Grease Quality Control Labs Bearing Testing Facilities Tribology Research Institutes For Pricing and additonal details kindly write or call us.

Send Message

Grease Testing Equipment

Water Washout Tester

Water Washout Tester As per ASTM D1264 The water washout apparatus is suitable for testing water washout characteristics of grease as per ASTM D1264. A sample of the lubricating grease under evaluation is tested in a bearing rotating under specific speed by spraying heated water and the loss of grease is determined. A tank is provided to hold about 750 ml of water with heating arrangement for heating the water to up to temperature 80°C. The equipment is provided with test bearing housing assembly as specified in the test method. The digital temperature controller with sensor is also provided for accurate indication of the temperature inside the equipment. The unit is provided with a ball bearing (ASTM 204) as specified in the test method. Circulating pump provided with a supply pressure and a return suction line, regulating valves, a splash nozzle and accessory.The pump is capable of delivering 300 ml/min heated water via 1mm capillary. The water containing washed out grease is collected in the tank, filtered & recycled during the test. Provision is made for fine adjustable of water flow through a bypass to allow the preheated water to circulate without passing through the jet or impinge on bearing housing. Features The bearing rotational speed is 600 ± 30 rpm. Supplied with test bearings – 2 Nos. Drain valve to remove the tested water. Provided with necessary tools and fixtures for assembling of bearing housing. Power supply : 120 V / 230 AC, Single Phase, 50 / 60 Hz

Send Message

Grease Testing Equipment

Lab Scale Grease Making Bath - Open Kettle Type

A lab-scale open kettle grease making bath is a customized apparatus used in the laboratory for small-scale grease manufacturing. It features a stainless-steel open kettle where various components, including base oils and thickening agents, are blended, and heated to create a uniform grease mixture. This equipment is invaluable for researchers and engineers to experiment with different grease formulations, refine existing ones, and examine the intricacies of grease manufacturing processes. The open design of the kettle facilitates easy access for monitoring and sampling during production, making it an essential tool for advancing knowledge in the realm of grease manufacturing. Capacity Offered : 5 Kg , 10 Kg , 25 Kg , 50 Kg and 100 Kg.

Send Message

Grease Testing Equipment

Grease Kettle Pressure Vessel Type

INR 350000

Send Message

Grease Testing Equipment

Grease Making Bath - Open Kettle Type

INR 150000 ~~INR 165000~~

Send Message

Grease Testing Equipment

Drop Point of Grease Wide High Temperature Range

Drop Point of Grease Wide High Temperature Range The ASTM D2265 dropping point tester is used for high temperature grease testing than the ASTM D566 method. This equipment uses a different heating procedure as compared with ASTM D566. The test cell is inserted in an aluminum block oven maintained at a constant temperature that is higher than the expected dropping point of the sample. The sample temperature then rises to the dropping point without operator control. The equipment can be offered with Two / Four / Six sample testing capability. Maximum Temperature is 400 °C.
